GENERAL SPECIFICATIONS
8 MODE switch
Selects the video output mode.
MODE switch details
Standard/
Double scan
Standard
Double scan
Standard
Double scan
Standard
Double scan
Standard
Double scan
Output
mode
VBS,Y/C
RGB
RGB
VBS,Y/C
RGB
RGB
SW5 SW6 Baud rate (bps)
ON ON 19200
OFF ON 9600
ON OFF 4800
OFF OFF 2400
7 Baud rate switch
Selects the baud rate for the RS-232C.
Baud rate switch (8-bit DIP switch)
Functions of bits : Factory preset values
(Note)
SW7 should always be set to OFF.
SW8 should always be set to ON.
Baud rates available with SW 5 and 6
Switch No. Function ON OFF
1 Parity Yes No
2 Parity polarity Even Odd
3 Character bits 8 bits 7 bits
4 Stop bits 2 bits 1 bit
5
Baud rate setting See table below.
6
7 Reserved
8 Reserved
Signal name
FG ............................. Frame Ground
TxD ...................... Transmitted Data
RxD ............................ Received Data
RTS ........................ Request to Send
CTS ............................. Cleat to Send
DSR .......................... Data Set Ready
SG ............................. Signal Ground
(Note)
(Note)
SW
No.
0
1
2
4
5
8
9
A
C
D
Output Mode Details
Frequency
mode
NTSC
PAL
NTSC
PAL
Middle cut
recovery
mode
OFF
OFF
ON
ON
•
The factory preset is “8” for RMD-V3104U.
•
Frequency mode
NTSC ........................ Vertical refresh rate 59.94Hz
PAL ........................... Vertical refresh rate 50.00Hz
•
Output mode
VBS (Video signal), Y/C or RGB is able to selected.
Yet, VBS, Y/C output are useful is only NTSC Standard
mode.
•
Standard / Double scan
Standard (Interlace) ................................................
................. Horizontal frequency 15.625kHz(PAL),
.............. Horizontal frequency 15.734 kHz(NTSC)
Double scan (Non-interlace) ..................................
................ Horizontal frequency 31.250 kHz(PAL),
.............. Horizontal frequency 31.468 kHz(NTSC)
•
Output mode
It is the function that mitigates the trunk piece
phenomenon by multiple visions unique scanning line
structure. There is a difference in an effect by the
magnification ratio and it is more effective as smaller of
the magnification ratio. Yet, it does not work in vertical
magnification ratio X 1.
CAUTION:
The Frequency mode for each input board is as follows.
Variable scan board ................................. NTSC, PAL
PAL / NTSC input board .............................................
.................. NTSC (NTSC source), PAL (PAL source)
In the case that a MODE NO other than the above is
set up, a proper picture is not output.
