86
ADJUSTMENTS
0. ID CLEAR
OK? PUSH 5 KEY
[1] Use the
ADJ IN
key to start up all the screens in the adjustment mode.
[2] The main menu is displayed. Press the
1
key to select “1. ID SET/CLEAR/SELECT”.
[3] Check that the ID indicator at the top left of the screen reads “—”, then press the
1
key to select “1.
ID SET”.
If ID numbers are already assigned, press the
0
key to select “0. ID CLEAR” from the main menu.
When this is done, the ID clear verification display appears as shown in the diagram. Now press the
5
key to return to “
1
Enter adjustment mode”, then assign the ID number.
[4] The ID input standby mode is set. Use keys
0
to
9
and
A
to
F
to input the ID
numbers.
[5] To adjust multiple screen multi projection units, return to “[1] Enter adjustment mode”, then assign the
ID number for the next multi projection unit.
NOTE) To return to the main menu display after assigning the IDs for all the screens, operate the
ADJ IN
key.
