132
ADJUSTMENTS
12) 8
• Selects “8” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Cyclically selects TV SYSTEM in the OPERATION MODE in the following order.
3 AUTO 3 NTSC 3 PAL
• Cyclically selects the item to be adjusted in the CONVERGENCE ADJUST MODE in the following order.
3 PIN 3 MID PIN 3 4D PIN 3 MID 4D PIN
• Moves the point to be adjusted down in the POINT CONVER ADJUST MODE.
• Selects GREEN HIGH-LIGHT in the WHITE BALANCE ADJUST MODE.
• Selects H BLK-R in the DEFLECTION ADJUST MODE.
13) 9
• Selects “9” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Cyclically selects TV SYSTEM in the OPERATION MODE in the following order.
3 1 3 2 3 3
• Selects V MID LINEARITY in the DEFLECTION ADJUST MODE.
• Cyclically selects the item to be adjusted in the CONVERGENCE ADJUST MODE in the following order.
3 SUB PIN 3 MID SUB PIN 3 4D SUB PIN 3 MID 4D SUB PIN
• Selects BLUE HIGH-LIGHT in the WHITE BALANCE ADJUST MODE.
14) A
• Selects “A” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Subtracts 10 from the current CONTRAST adjusting value in the DEFLECTION ADJUST MODE, CONVER-
GENCE ADJUST MODE, and POINT CONVER ADJUST MODE.(Returns to the original adjusting value
when the adjustment mode is exited.)
• Selects RED LOW-LIGHT in the WHITE BALANCE ADJUST MODE.
15) B
• Selects “B” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Selects H PIN in the DEFLECTION ADJUST MODE.
• Selects GREEN LOW-LIGHT in the WHITE BALANCE ADJUST MODE.
16) C
• Selects “C” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Adds 10 to the current CONTRAST adjusting value in the DEFLECTION ADJUST MODE, CONVERGENCE
ADJUST MODE, and POINT CONVER ADJUST MODE.(Returns to the original adjusting value when the
adjustment mode is exited.)
• Selects BLUE LOW-LIGHT in the WHITE BALANCE ADJUST MODE.
17) D
• Selects “D” for ID SET and ID SELECT in the ID SET/CLEAR/SELECT MODE.
• Selects GH LINEARITY in the DEFLECTION ADJUST MODE.
(Note: This adjustment item is the same as GH LINEARITY in the convergence ADJUST MODE.)
• Selects ABL LEVEL in the WHITE BALANCE ADJUST MODE. (It is validity at COMBINATION=ON.)
