118
ADJUSTMENTS
ABL operation link level adjustment (Note 1)
Adjustment mode exit
Adjustment mode start-up
R,G,B all color off
R,G,B all color on
ABL gain adjustment
Adjusts BV STATIC
Adjusts BV SIZE
Adjusts BV LINEARITY
Adjusts MID SIZE
Adjusts MID LIN
Adjusts BV SKEW
Adjusts BV KEY
Adjusts BV SUB KEY
Adjusts BV MID KEY
Adjusts BV MID S-KEY
Adjusts BV 5D SKEW
Adjusts BV BOW
Adjusts BV PIN
Adjusts BV SUB PIN
Adjusts BV MID PIN
Adjusts BV MID S-PIN
Adjusts BV 6D BOW
Adjusts BV 3D SKEW
Adjusts BV 3D KEY
Adjusts BV 3D SUB KEY
Adjusts BV MID 3D KEY
Adjusts BV MID 3D S-KEY
Adjusts BV 5D SIZE
Adjusts BV 4D BOW
Adjusts BV 4D PIN
Adjusts BV 4D SUB PIN
Adjusts BV MID 4D PIN
Adjusts BV MID 4D S-PIN
Adjusts BV 6D LIN
Adjusts BH STATIC
Adjusts BH SKEW
Adjusts BH BOW
Adjusts BH 3D SKEW
Adjusts BH 4D BOW
Adjusts BH SIZE
Adjusts BH KEY
Adjusts BH PIN
2 RS-232C commands table
Com-
mand
Name
Normal
Valid
Number
Direct
Function
UP/DW
Command
A ABL ABL LEVEL X √ √
AJN ADJUST NO X X X
AJY ADJUST YES √ X X
AOF ALL OFF √ X X
AON ALL ON √ X X
ABG ABL GAIN X √ √
B B00 BLUE 00 X √ √
B01 BLUE 01 X √ √
B02 BLUE 02 X √ √
B03 BLUE 03 X √ √
B04 BLUE 04 X √ √
B06 BLUE 06 X √ √
B07 BLUE 07 X √ √
B08 BLUE 08 X √ √
B09 BLUE 09 X √ √
B10 BLUE 10 X √ √
B11 BLUE 11 X √ √
B12 BLUE 12 X √ √
B13 BLUE 13 X √ √
B14 BLUE 14 X √ √
B15 BLUE 15 X √ √
B16 BLUE 16 X √ √
B17 BLUE 17 X √ √
B18 BLUE 18 X √ √
B19 BLUE 19 X √ √
B20 BLUE 20 X √ √
B21 BLUE 21 X √ √
B22 BLUE 22 X √ √
B23 BLUE 23 X √ √
B24 BLUE 24 X √ √
B25 BLUE 25 X √ √
B26 BLUE 26 X √ √
B27 BLUE 27 X √ √
B28 BLUE 28 X √ √
B29 BLUE 29 X √ √
B30 BLUE 30 X √ √
B31 BLUE 31 X √ √
B32 BLUE 32 X √ √
B33 BLUE 33 X √ √
B34 BLUE 34 X √ √
B36 BLUE 36 X √ √
B37 BLUE 37 X √ √
B38 BLUE 38 X √ √
