ADJUSTMENTS
NOTES) ¶ The set operates as follows when the above is displayed:
• No key is pressed = Adjustment mode is canceled after about 180 seconds.
• “MAIN MENU” or “ADJ IN” pressed = Main menu reappears.
• “ADJ OUT” pressed = Adjustment mode is canceled.
• Any key from “0” to “D” pressed = W/B adjustment mode corresponding to that key is set.
¶ The adjustment settings cannot be changed when the above adjustment settings are displayed.
• Status display turns on and off cyclically.
32)
•
Moves the convergence down in the POINT CONVER ADJUST MODE.
33) ADJ OUT
•
Exits the adjustment mode.
34) LED for Confirming Transmission
Adjustment
setting 4UP
Adjustment
setting 4UP
Adjustment
setting 4UP
Adjacent bar set to medium bar Set to large bar
Set to medium bar
