78
ADJUSTMENTS
Signal Name
Monoscope
Crosshatch
Tilted crosshatch
White signal
(Can be linearly varied between 0% and 100%)
Or 10 step
Crosshatch
Moving image (scenery, faces)
Color-bar, etc.
Adjustment
• Screen center adjustment
Screen size adjustment
• Convergence adjustment
• White balance adjustment
• Linear white adjustment
• Total adjustment
(Color, tint, etc.)
(2) Processing of wires
¶ When installing for long periods of time (such as for permanent installations rather than short-term events),
use wires of the appropriate length considering the overall routing of the wiring.
¶ Make sure that the connection terminals are not subject to direct loads or forces. For short-term installation
the wires can be bound together by string, etc., but for long-term installations they should be properly bound.
(3) Aging
¶ After turning on the power, input the 100% white signal or moving images, and perform aging until multi
projection unit stabilizes (about 1 hour). If adjustments are performed without aging, as it takes time until
Multi projection unit will warm up and stabilize, convergence and white balance will become incorrect.
(4) Adjustment signals
¶ Use the composite video signal for adjustments created in the multi video processor. When converters not
creating the signals for adjustment are used, supply the signals for adjustment from equivalent signal
sources (signal generator, LD player, etc.)
Generally required signals
