ADJUSTMENTS
[4] (GET W/B DATA) — White balance adjustment data is output.
Format : Output in the following order.
1 STX (02H)
2 / LINEAR WHITE
adjustment data (3 BYTE)
3 /CONTRAST adjustment data (3 BYTE)
4 /BRIGHTNESS adjustment data (3 BYTE)
5 /COLOR adjustment data (3 BYTE) (Note 1)
6 /TINT adjustment data (3 BYTE) (Note 1) and (Note 3)
7 /BLUE LOW-LIGHT adjustment data (3 BYTE)
8 /GREEN LOW-LIGHT adjustment data (3 BYTE)
9 /RED LOW-LIGHT adjustment data (3 BYTE)
0 /BLUE HIGH-LIGHT adjustment data (3 BYTE)
- /GREEN HIGH-LIGHT adjustment data (3 BYTE)
= /RED HIGH-LIGHT adjustment data (3 BYTE)
~ /SHARPNESS adjustment data (3 BYTE) (Note 1) and (Note 5)
! /ABL LEVEL adjustment data (3 BYTE) (Note 4)
@ /ABL GAIN adjustment data (3 BYTE) (Note 2)
# ETX (03H)
(Note 1) Dummy when INPUT=RGB
(Note 2) No dependent on mode. (Has one data.)
(Note 3) Dummy when PAL signal is input. (INPUT=VIDEO or Y/C)
(Note 4) Dummy when COMBINATION=OFF (Data is output when COMBINATION=ON)
(Note 5) SHARPNESS data for OFF is output when MULTI=OFF, and SHARPNESS data for ON is output when
MULTI=ON.
[5] GVO (GET ABL VOLTAGE) — The ABL voltage is converted within the range of 0 to 5V, identified in 256 steps
and output. (3 BYTE)
[6] (GET CONV. USER DATA) — Deflection and convergence data memory area setting state is output.
1 STX (02H)
2 Memory area selected when INPUT=VIDEO or Y/C & input signal=NTSC.
(3 BYTE)
Example)US 1:Indicates CONV.MEMO-1 is selected.
3 Memory area selected when INPUT=VIDEO or Y/C & input signal=PAL
(Or other than NTSC, containing no signals). (3 BYTE)
Example)US 2:Indicates CONV.MEMO-2 is selected.
4 Memory area selected when INPUT=RGB & input signal=NTSC. (3 BYTE)
Example)US 1:Indicates CONV.MEMO-1 is selected.
5 Memory area selected when INPUT=RGB & input signal=PAL
(Or other than NTSC, containing no signals). (3 BYTE)
Example)US 2:Indicates CONV.MEMO-2 is selected.
6 IETX (03H)
