Using Office-to-Office Connections 15-9
Configuration Steps for an Office-to-Office Connection
Configuring Dial-Out Port Settings
For all ports on the PortMaster in Paris that you want enabled for dial-in and dial-out
(two-way service) to the Office Router in the London office, enter the values shown in
Table 15-7.
Leave all the other settings at their default values.
After you configure the port as shown in Table 15-7, enter the following commands to
reset the port and save the configuration:
Command> reset s1
Command> save all
For more information about asynchronous ports, refer to Chapter 5, “Configuring an
Asynchronous Port.”
Table 15-7 Two-Way Port Values
Setting Command
Port type set s1 network twoway
Speed 1 set s1 speed 1 115200
Speed 2 set s1 speed 2 115200
Speed 3 set s1 speed 3 115200
Modem control set s1 cd on
Hardware flow control set s1 rts/cts on
Software flow control set s1 xon/xoff/off
Idle timer set s1 idle 5
Dial group set s1 group 1
