ISDN BRI Unnumbered IP Configuration Example
12-18 PortMaster Configuration Guide
Configuring a Dial-In User
A user account must be set up on the PortMaster router in San Francisco so that
PortMaster in Denver can dial in when traffic is queued. The new user denver should
be configured with the values shown in Table 12-11.
After you configure the user table as shown in Table 12-11, enter the following
command to save the configuration:
Command> save all
For more information about configuring user table parameters, refer to Chapter 7,
“Configuring Dial-In Users.”
Table 12-11 User Table Values
Setting Command
Username add netuser denver
Password set user denver password anypasswd
Protocol set user denver protocol ppp
User IP address set user denver address 192.168.200.1
Netmask set user denver netmask 255.255.255.0
IPX network set user denver ipxnet F3
RIP routing set user denver rip on
MTU set user denver mtu 1500
Compression set user denver compression on
