Using Synchronous V.25bis Connections 14-9
Configuration Steps for a Synchronous V.25bis Connection
After you configure the Ethernet interface as shown in Table 14-7, enter the following
command to save the configuration:
Command> save all
For more information on Ethernet settings, refer to Chapter 4, “Configuring the
Ethernet Interface.”
Configuring Synchronous WAN Port Settings
Configure the synchronous WAN port with the values shown in Table 14-8.
After you configure the synchronous WAN port as shown in Table 14-8, enter the
following commands to reset the port and save the configuration:
Command> reset w1
Command> save all
For more information about synchronous ports, refer to Chapter 6, “Configuring a
Synchronous WAN Port.”
Table 14-8 Synchronous WAN Port Values
Setting Command
Port type set w1 network twoway
Transport protocol set w1 protocol ppp
Netmask set w1 netmask 255.255.255.0
Modem control set w1 cd on
Group set w1 group 1
