Using ISDN BRI 12-11
ISDN BRI Unnumbered IP Configuration Example
For comparison, Figure 12-3 shows a similar configuration using ISDN BRI with
numbered interfaces.
Figure 12-3 ISDN BRI Numbered
Configuring the PortMaster in Denver
The PortMaster in Denver is being configured for an ISDN dial-up connection to the
PortMaster in San Francisco.
Configuring Global Settings
Configure the global settings on the PortMaster in Denver to the values shown in
Table 12-3.
After you configure the global settings shown in Table 12-3, enter the following
command to save the configuration:
Command> save all
For more information about global settings, refer to Chapter 3, “Configuring Global
Settings.”
Table 12-3 Global Values
Setting Command
IP gateway set gateway 192.168.1.1
System name set sysname denver
ISDN switch set isdn_switch ni-1
Internet
PM2 PM2
BRI BRI
PPP 10.0.0.0/24 PPP 10.0.0.2/24
Ether0 192.168.200.1/24 Ether0 192.168.100.1/24
11820026
S.F. Denver
