Lucent Technologies PortMaster User Manual
Page 105
Configuring a Synchronous WAN Port
6-3
Synchronous Port Uses
Figure 6-1
Synchronous WAN Connection
Once you have determined the type of synchronous connection to use between your
remote locations, the synchronous port on each end of the connection must be
configured.
IRX Router
IRX Router
11820004
Bangkok
New York
workstation 1
workstation 3
IRX Router
CSU/DSU
workstation 2
workstation 1
workstation 3
IRX Router
CSU/DSU
11820004
workstation 2
Frame
Relay
