Provisioning, Provisioning -3 – Lucent Technologies PortMaster User Manual
Page 187
Using ISDN BRI
12-3
Overview of ISDN BRI Connections
Figure 12-1 Example of an ISDN Connection
Provisioning
To help you determine the kind of provisioning you require for your ISDN setup, refer
to the information in the hardware installation guide and on the Lucent Remote Access
website at http://www.livingston.com.
System
Link Network
NT1
S1
S2
PortMaster 2e
11820006
New York
workstation 2
workstation 1
workstation 3
PortMaster
workstation 2
workstation 1
workstation 3
Office Router-ISDN
ISDN
PM-2E with
Bangkok
BRI module
