3-7
Chapter 3 Menu overview
Menu name Port number : Protocol name
——PORT 1 :XPT ——PDL SELECT
——XPT PORT
——PORT 2 : LPD ——PDL SELECT
——PRINTER NAME
Protocol ——PORT 3 : FTP ——PDL SELECT
——USER NAME
: :
: :
——PARALLEL ——PDL SELECT
Menu
name
——COMM. PARAM. ——ETHERNET ——PORT SELECT ——XLF
System
: (Refer to “Note” below.)
——PARALLEL ——TIMING MODE
:
——USB ——TIMEOUT (sec)
(2) Protocol menu
For each parallel channel and port in the Protocol menu, select the PDL
numbers in “PDL SELECT” as listed below. When the Protocol menu is
changed, system reset is executed.
▼Setting menu
Note:
You can set the ports you use in Ethernet parameters in System menu (initial
parameter is 3 ports).
(3) System menu
Set the number of ports you use and the protocol types in System menu
listed below:
Note:
FTP, XPT, and LDP comprehensively allow for 10 ports to be set.
Initial parameter is 1 port for each protocol. (XLF)
Setting example: # PORT SELECT 1-10
> F F F X X X L L L – ....... In case of 3 ports for each protocol
