5-21
▼Setting parameter items
Chapter 5 "SETUP" Menu
Automatic reduction
Paper feed direction
X
Y
Drawing
Drawing
SCALING PARAM.
This is a parameter group that allows you to set scale conditions.
■SCALE MODE
Allows for setting whether to apply the scale to the drawing manually or
allow the automatic reduction.
When the manual scale is selected, the scale is applied to the drawing
according to the setting of scale X, scale Y and scale FIX.
This setting is performed on the third hierarchy.
: Default value
MANUAL SCALE Automatic scaling does not take place. Manual scale
parameters (scale X and Y and fix scale) are enabled.
REDUCE Drawing is automatically reduced to be within the paper size.
