Xpt port, Printer name – Seiko Instruments SII Black-and-White Raster Plotter LP-1020 User Manual
Page 178

9-4
Example 1: When using the HPGL format only
Example 2: When using both the HPGL format and TIFF format
XPT PORT
Specifies the XPT port No. (numerical value)
0 to 65535
Default value: 91xx
xx: Port No.- 1
Do not use the same port number for multiple ports.
Numbers 0 to 1023 are reserved numbers and should not be used.
* XPT: Raw Protocol (socket)
PRINTER NAME
Specifies the LPD printer name (characters).
3 to 8 characters
Default value: LPxx
xx: Port No.
A to Z, 0 to 9, - (hyphen), and _ (under bar) can be used.
Do not use the same printer name in multiple ports.
# P D L
S E L E C T
> H -
# P D L
S E L E C T
> H -
T -
