2-46
Rolls of the China series listed below can also be used with this device.
Plotting of the fixed form cannot be performed with the roll of the China
series. All the plots produced in this mode are in the actual length.
Operation when using the China series is described below.
(1) Adding new media series
Set the China series to ON in the valid series setting process (page 11-5).
(2) Setting the China size
Four types of A0 width, 2 types of A1 width and 2 types of A2 width of
the China series can be used. Set the required width in the Chinese size
(page 11-8).
Using paper of Chinese standard series
China A0 roll
width
China A1 roll
width
China A2 roll
width
China A3 roll
width
914 mm
(36 inches)
620 mm
(24.4 inches)
450 mm
(17.7 inches)
310 mm
(12.2 inches)
910 mm
(35.8 inches)
610 mm
(24 inches)
440 mm
(17.3 inches)
297 mm
(11.7 inches)
900 mm
(35.4 inches)
- - -
880 mm
(34.6 inches)
- - -
Note
Note
◆If this setting is changed, the device must be restarted.
◆If this setting is changed, the device must be restarted.
