Appendix-2
Basic specifications
Plotter Specification
■ Basic Specifications of Plotter
(1/2)
Items
Specifications/Functions
LP-1020 LP-1020L
Recording method Electrophotographic method (LED exposure)
Developing method Dry development (one component)
Type of photosensitive
element
OPC
Fusing system Heat roller
Resolution 600 dpi
Continuous print speed
A0 (ortrait) : 3.4 sheets/min
A1 (portrait) : 4.6 sheets/min
A2 (portrait) : 6.2 sheets/min
A3 (portrait) : 8.0 sheets/min
A3 (landscape) : 8.8 sheets/min
A4 (landscape) : 10.6 sheets/min
Paper feed configuration/
Delivery direction
Max. triple rolls, manual feeding/Front delivery
Type of paper
Plain paper
Recycled paper
Tracing paper
Mat film
Paper size
Rolled paper (width) A0/A1/A2/A3, 36” /24” /18” /12”
Cut paper: A0/A1/A2/A3
Max. output length 2.5 m (98.4 inches) 10 m (393.7 inches)
Warming up time 4 minutes or less 8 minutes or less
First prin Within 28 secconds/A0 drawing
Plotting guarantee area
(Rolled paper only)
All areas except margin 5 mm (0.2 inches) at top/margin 12 mm
(0.47 inches) at bottom/margin 3 mm (0.12 inches) on each side
Data format D-SCAN, HP-GL, HP-GL/2, HP RTL, TIFF, CALS
HDD 40GB (optional) 40GB
Interface
Standard:
Ethernet (10/100BASE)
Optional:
USB2.0, Centronics
Standard:
Ethernet (10/100BASE)
USB2.0, Centronics
Network protocol TCP/IP (ftp, lpr, xpt)
