14-37
Chapter 14 Troubleshooting
When a print error occurs
This section explains how to solve print quality problems. Take
appropriate measures according to the symptoms.
■Measures to solve print quality problems
◆ When there is a space between drawings, the end of the roll
paper can be cut automatically before the next plotting.
⇒ “EDGE CUT TIMER” on page 6-4
Symptom Cause Corrective measure
Plotting is
light/dark
---------- Adjust the density. ⇒ Page 6-5
Plotting is locally
deleted
The type of loaded paper does
not match the type of paper
specified on the panel.
Replace the paper, or change the
setting. ⇒ Page 2-16 or 7-2
Paper contains moisture.
Cut the end of the rolled paper and
retry plotting.
⇒ Page 14-11
The recommended paper is not
used. Use our recommended paper.
⇒ Page 1-7
Plotting is locally
streaked
Process cartridge reached its
life. Replace the process cartridge.
⇒ Page 2-28
