5-25
▼Setting parameter items
Chapter 5 "SETUP" Menu
■GRAPHIC LANG. (HP-GL only)
Allows to set whether to handle the data received as HP-GL or HP-GL/2.
Data handling is done automatically in the AUTO setting. The origin
coordinates affected depending on HP-GL or HP-GL/2. This setting is
performed on the third hierarchy.
: Default value
AUTO Judges HP-GL or HP-GL/2 automatically.
HP-GL/2 Judges the data received as HOP-GL/2.
HP-GL Judges the data received as HP-GL.
When HP-GL is employed, the origin of coordinates should be the center
point. When HP-GL/2 is employed, the origin of coordinates should be
the left lower point.
When HP-GL is employed, HP-GL/2 data can be received without
causing an error.
■TERMINATOR (HP-GL only)
TERMINATOR PG1;
TERMINATOR NR;
TERMINATOR SPO;
TERMINATOR ESC. )
TERMINATOR AF;
TERMINATOR AH;
TERMINATOR FR;
Allows for setting whether the terminator is to be a condition to complete
the drawing for each command. When pen 0 is used as an ordinary pen,
set the terminator SP0 to OFF. This setting is performed on the third
hierarchy.
: Default value
ON Sets the command to terminator (EOF).
OFF Does not set the command to terminator (EOF).
