5-33
▼Setting parameter items
Chapter 5 "SETUP" Menu
■LINE DISPOSAL
Allows for setting of the end shape of fine small lines and their joining
method.
: Default value
OFF : Line end shapes other than round one are treated.
ON : All ends of fine small lines are treated as round shape.
• With this device, lines less than 1mm (0.039 inches) in width and
length are handled as micro-length lines.
• Fine small lines may not be clearly plotted in combinations other than
CORNER = "ROUND" and JOINT = "ROUND".
By setting the parameter to "ON", the lines are handled as CORNER
= "ROUND" and JOINT = "ROUND" allowing clear plotting.
