2-37
Chapter 2 Basic operations
Map series fixed form cut paper
Name of fixed
form
Lengthwise length Widthwise length
B1 1000.0 mm (39.4 inches) 700.0 mm (27.6 inches)
B2 700.0 mm (27.6 inches) 500.0 mm (19.7 inches)
Map series width cut paper
Width name Paper width Paper length
B1 width 700.0 mm (27.6 inches)
Max. up to printing length
B2 width 500.0 mm (19.7 inches)
DIN series fixed form cut paper
Name of fixed
form
Lengthwise length Widthwise length
B1 1000.0 mm (39.4 inches) 707.0 mm (27.8 inches)
B2 707.0 mm (27.8 inches) 500.0 mm (19.7 inches)
B3 500.0 mm (19.7 inches) 353.0 mm (13.9 inches)
DIN series width cut paper
Width name Paper width Paper length
B1 width 707.0 mm (27.8 inches)
Max. up to printing length
B2 width 500.0 mm (19.7 inches)
Chinese series width cut paper
Width name Paper width Paper length
914 mm width 914 mm (36 inches)
Max. up to printing length
910 mm width 910 mm (35.8 inches)
900 mm width 900 mm (35.4 inches)
880 mm width 880 mm (34.6 inches)
620 mm width 620 mm (24.4 inches)
610 mm width 610 mm (24 inches)
450 mm width 450 mm (17.7 inches)
440 mm width 440 mm (17.3 inches)
310 mm width 310 mm (12.2 inches)
297 mm width 297 mm (11.7 inches)
▼Manual paper feeding (cut paper)
