2-11
Chapter 2 Basic operations
Press the key.
Press the key.
*Printing will be cancelled.
or
Replacing paper rolls
or
or
◆ When a paper replacement message appears on the LCD, it is
possible to cancel the drawing that you sent to print. Use this
function when you don’t have the required paper.
Example)
How to detach and reattach the paper rolls will be explained here.
Detach and replace a paper roll when the device has run out of paper or
when you change the paper roll size on type. When the paper is used up
during printing, the Error lamp will turn on and the LCD will display the
following message:
Example: The screen requesting the A3 tracing paper to be loaded in the
roll 1 drawer.
S E T P A P E R
A 0
S E T P A P E R
R O L L 1 A 0
S E T P A P E R
A 0 ( T R A C E )
S E T P A P E R
R O L L 1 A 0 ( T R A C E )
S E T P A P E R
A 1
C A N C E L P R I N T ?
P R I N T R E A D Y
