3-11
Chapter 3 Menu overview
Press the key
Menu screen
When the device is online and you press the key to go offline, a menu
screen appears. Select a menu using the , keys and press the
key to enter each menu.
Menu Item Functions
Sets the PDL table parameter settings for Ethernet port n.
PORT n_HPGL Performs the settings relating to HPGL format
printing.
Sets the PDL table parameter settings for Ethernet port n.
PORT n_DSCAN Performs the settings relating to DSCAN
format printing.
Setup
Sets PDL table parameter settings for Ethernet port n.
PORT n_TIFF Perform the settings relating to TIFF format
printing.
Sets PDL table parameter settings for Ethernet port n.
PORT n_CALS Performs the settings relating to CALS format
printing.
M E N U
# S E T U P
S E T U P
# P O R T 1 _ H P G L
Setup menu “SETUP”
Press the key on the display indicated below to enter the Setup menu.
Perform PDL parameter settings.
For PDL parameter settings, set printing mode etc. The Setup menu also
contains the following items.
