1-2
Features
This device is an electrophotographic black-and-white raster plotter
which produces plots by receiving graphic data created by a work station
or PC (hereafter referred to as a computer.)
This device is equipped with the following features:
High speed plotting
output, high resolution
2-roll paper feeding
mechanism, long drawing
compatible
This device has 80 mm (3.15 inches)/sec recording speed and
can output A0 size drawings at 3.4 sheets per minute. It can also
output high accuracy drawings at 600 dpi resolution.
This device employs a 2-roll paper feeding mechanism that sets
2 sizes from a choice of 4 sizes: A0 size (or 36 inch size), A1 (or
24 inch size), A2 (or 18 inch size), and A3 (or 12 inch size). By
employing paper rolls compatible with drawing sizes ranging
from A0 to A4, a low running cost is achieved by reducing paper
consumption.
This device can also output 2.5 m / 98.4 inch size (10 m / 393.7
inch for the LP-1020L) long sheet drawings. The maximum
plotting range of this device is as follows:
(Note)
Picture quality and printing accuracy can only be assured for plain paper
and recycled paper. (Only up to twice the length of the standard-size
paper can be assured for tracing paper and film.)
LP-1020
• A0 size paper roll : 841 × 2500 mm (33.1 × 98.4 inches)
• A1 size paper roll : 594 × 1830 mm (23.4 × 72 inches)
• A2 size paper roll : 420 × 1200 mm (16.5 × 47.2 inches)
• A3 size paper roll : 297 × 920 mm (11.7 × 36.2 inches)
LP-1020L
• A0 size paper roll : 841 × 10,000 mm (33.1 × 393.7 inches)
• A1 size paper roll : 594 × 10,000 mm (23.4 × 393.7 inches)
• A2 size paper roll : 420 × 1220 mm (16.5 × 47.2 inches)
• A3 size paper roll : 297 × 920 mm (11.7 × 36.2 inches)
