3-5
Chapter 3 Menu overview
Settings menu
This device has menus for setting printing parameters, system settings for
the entire device, communication protocols, and operation status settings
for the device engine.
1 Setup menu Sets printing parameters etc.
2 System menu Sets system settings for the entire device.
3 Protocol menu Sets communication protocol settings.
4 Device menu Sets operating status settings for the device
engine.
Moreover, this device has four Print parameter setup tables to be used
independently for each of the parallel channels and Ethernet ports. These
tables can be set from the Setup menu (this Setup table is referred to as the
PDL table hereafter).
These four PDL tables can be assigned to each channel or port via “PDL
SELECT” in the Protocol menu (the USB channel cannot be changed).
Set the number of ports you use and the protocol type in “PORT
SELECT” from Communication parameters in the System menu.
