11-2
Setting items
After this menu is changed, the parameters are automatically saved and
the system is reset. When there is a job standing for processing, you can
only refer to this menu. If you only refer to the menu and do not change
it, the system returns to the offline condition.
S Y S T E M
# C O M M . P A R A M
Menu First hierarchy item Second hierarchy item Third hierarchy item Parameter
SYSTEM
SYSTEM
#COMM.PARAM
COMM.PARAM
#ETHERNET
Note 1)
COMM.PARAM
#PARALLEL
TIMING MODE
NORMAL
NORMAL
FAST
SLOW
#TIME OUT (100 msec)
>300
1 to 18000
COMM.PARAM
#USB #TIME OUT (sec)
>10
0 to 99
COMM.PARAM
#PlotDataToFile
#PDTF HostIP Adress
>000.000.000.000
000.000.000.000
to
255.255.255.255
#PDTF PORT
>33000
0 to 65535
#PDTF Timeout (sec)
>33000
1 to 75
COMM.PARAM
#Terioplot
#Terioplot
>OFF OFF
ON
#Terioplot ADDR
>000.000.000.000
000.000.000.000
to
255.255.255.255
#WEB LOCK
>OFF
- -
OFF
ON
SYSTEM
#ENABLE SERIES
Note 2)
SYSTEM
#APPLY ROLL
Note 3)
SYSTEM
#CHINA SIZE
Note 4)
#INITIAL SET
>STANDARD
- -
STANDARD
CHINA
#LANGUAGE
>JAPANESE
- -
ENGLISH
JAPANESE
#LENGTH UNITS
>MILLIMETERS
- -
MILLIMETERS
INCHES
#ADMIN PASSWORD
>00000000
00000000
to
99999999
Note 1) Refer to the chapter of Ethernet parameter.
Note 2) Refer to the "Enable series".
Note 3) Refer to the "Apply roll".
Note 4) Refer to the "China size".
