Page 51: E-1 programmed recording settings
English
Recording settings
How to set
50
This menu is used to set the desired cameras for each
group (P-1, P-2, P-3 and P-4) for programmed recording.
For each group, cameras are selected to enable or
disable recording from them, and their individual
recording rates are also set here.
After this setting is completed, the program number
(P-1~P-4) can be selected for "REC PROGRAM GROUP"
on the
1
PROGRAM number
Selects the program number.
Selections: P-1/P-2/P-3/P-4
2
SELECT INDIVIDUAL CAMERA RATE (FPS)
Enables or disables cameras for recording, and sets their
individual recording rates. The default setting for recording
rate is 0.5.
Selections: 25/12.5/6.25/3.125/1.533/1/0.5/0.33/0.25/0.2/
0.1/0.05/0.033FPS/OFF
3
NORMAL REC
Displays the possible recording time for each group, based
on the program settings.
1
Display the
explained in "Displaying the recording settings
screen", and then turn the S-dial clockwise. (P39)
The "P-1" starts blinking.
2
Turn the J-dial to select the desired PROGRAM
number (example: P-2), and then turn the S-dial
twice clockwise.
The "0.5" indicator starts blinking.
3
Turn the J-dial to select the rate for "01" (example:
6.25), and then turn the S-dial clockwise.
4
Turn the J-dial, select "02", and turn the S-dial
clockwise.
5
Turn the J-dial to select the rate (example: 12.5),
and then turn the S-dial clockwise.
Repeat the same procedure to select the desired
recording rates.
The possible recording time of the normal recording
area is displayed, and the cursor moves to the program
number.
6
Turn the J-dial to select other programs (P-2~P-4)
and enable or disable recording from the individual
cameras, and set their recording rates.
7
Press the EXIT/OSD button to end the setting
procedure.
E
Programmed recording menu
description
The recording rate is limited by the pre-alarm and
mirroring settings. (P85)
PROGRAM : P-4
SELECT INDIVIDUAL CAMERA RATE(FPS)
01: 0.5 02: 0.5 03: 0.5
04: 0.5 05: 0.5 06: 0.5
NORMAL REC : 67H
PROGRAM : P-3
SELECT INDIVIDUAL CAMERA RATE(FPS)
01: 0.5 02: 0.5 03: 0.5
04: 0.5 05: 0.5 06: 0.5
NORMAL REC : 67H
PROGRAM : P-2
SELECT INDIVIDUAL CAMERA RATE(FPS)
01: 0.5 02: 0.5 03: 0.5
04: 0.5 05: 0.5 06: 0.5
NORMAL REC : 67H
PROGRAM : P-1
SELECT INDIVIDUAL CAMERA RATE(FPS)
01: 0.5 02: 0.5 03: 0.5
04: 0.5 05: 0.5 06: 0.5
NORMAL REC : 67H
1
2
3
E-1
Programmed recording settings
MENU
(J)
(S)
PROGRAM : P-1
SELECT INDIVIDUAL CAMERA RATE(FPS)
01: 0.5 02: 0.5 03: 0.5
04: 0.5 05: 0.5 06: 0.5
NORMAL REC : 67H
5.PROGRAM REC SET
2.RECORD SET
01: 0.5
01: 6.25 02: 12.5 03: 0.5 04: 0.5
EXIT/OSD
