English
Recording settings
How to set 40
The following two easy settings are available.
☞
RECORDING DURATION BASE (P41)
☞
REC RATE BASE (P42)
(Menu item - Description)
1 RECORDING DURATION
1 to 99 can be selected. The default setting is 1.
2 TIMER RECORDING (DLY)
The timer-controlled recording can be switched ON or
OFF.
When "OFF" is set, the cursor does not move to the
START time.
3 PICTURE QUALITY
Selections:
BASIC (BA): Rough image quality, approx. 15kB
NORMAL (NO): Standard image quality, approx. 22kB
ENHANCED (EN): Enhanced image quality, approx.
30kB
FINE (FI): Fine image quality, approx. 42kB
SUPER FINE (SF): Super fine image quality, approx.
50kB
4 AUDIO RECORDING
Audio recording can be switched ON or OFF. Audio
recording can only be set if the recording rate is between
1~50 FPS. When the audio recording is "ON", the letter A
will be displayed in front of the recording rate. Since both
audio and video will be stored in the normal recording
area, the number of images that can be recorded is
reduced.
If the recording rate is out of the specified range, audio will
not be recorded.
5 NUMBER OF CAMERAS
Displays the number of cameras connected to the DVR.
6 REC RATE
Displays the maximum recording rate per camera based
on the other settings of this menu and the number of
cameras. If a valid number cannot be calculated,
"ERROR!" will be displayed.
Modify the settings to resolve the problem.
1 REC RATE
Selections:
50, 25, 16.67, 12.5, 8.333 ,6.25, 5, 4.167, 3.571, 3.125,
2.778, 2.5, 2.273, 1.923, 1.667, 1.471, 1.316, 1.190,
1.087, 1, 0.5, 0.333, 0.25, 0.2, 0.1, 0.05, 0.033
Audio recording can only be set when this setting is within
the range of 50~1 FPS.
2 RECORDING DURATION
Displays the maximum recording duration per camera
based on the other settings of this menu and the number
of cameras. If a valid number cannot be calculated,
"ERROR!" will be displayed.
Modify the settings to resolve the problem.
A Easy recording menu description
RECORDING DURATION : -- DAYS
TIMER RECORDING(DLY) : OFF
START --:-- STOP --:--
PICTURE QUALITY : ENHANCED
AUDIO RECORDING : OFF
NUMBER OF CAMERAS : 2
REC RATE : ------FPS/CAM
1
3
5
6
2
4
1
2
REC RATE : ----- FPS/CAM
TIMER RECORDING(DLY) : OFF
START --:-- STOP --:--
PICTURE QUALITY : ENHANCED
AUDIO RECORDING : OFF
NUMBER OF CAMERAS : 2
RECORDING DURATION : ---- DAYS
The easy recording settings will be erased when the
following occur:
• When the number of cameras detected by this DVR
increases or decreases.
• Using the , the pre-alarm
recording is switched to "ON".
• Menu settings are loaded from a CompactFlash
card.
• A different easy recording setting is performed.
• The normal recording settings or timer settings are
modified.
• The recording areas of the hard disk are modified.
• When mirroring settings were changed under the
hard disk settings.
• When the hard disk was changed.
• When a hard disk was added.
