Searching for recorded video
How to use 24
Plays back video stored in the archive area.
1 Press the SEARCH button during recording or live
video.
2 Turn the J-dial, select "ARCHIVE AREA SEARCH",
and turn the S-dial clockwise.
The screen is displayed.
The eight most recent archive recordings are displayed
in the order of archiving.
☞ Press the SEARCH button to cancel the search
mode.
Operation returns to the normal screen.
(Menu item - Description)
1 NO:
Displays the number of the archive.
2 DATE:
Displays the date of recording.
3 START:
Displays the start time of recording.
4 CH:
Displays the lead channel (camera number) of the recording.
5 TOTAL:
Displays the total capacity of the archive area.
6 USED:
Displays the amount of the archive area that has been used.
3 Select the desired "NO" by turning the J-dial, and
turn the S-dial clockwise.
The selected video is displayed in the preview screen,
and playback starts in full-screen mode. When the
selected video is over, playback pauses.
4 Press the PLAY/STOP button.
• Select the search area and the channel number on the
screen. Selecting
the will display the DETECTION SEARCH 2> screen.
• The screen displays
the specified search area and channel number. Set the
start and end date/time, and select "MOTION SENSOR" to
display the motion sensor setting screen.
• On the motion sensor setting screen, set the motion
sensor for the recorded images and detect scenes where
images were changed by intruders etc.
(Menu item - Description)
screen
1 SEARCH FROM/START/END
When selecting a recording area for the motion sensor setting, the
date and time of the first and last recording in the selected
recording area will be displayed automatically. The starting and
ending date and time cannot be changed.
Selections:
• ALARM: Searches video from the alarm recording area.
• NORMAL: Searches video from the normal recording area.
• ALARM & NORMAL:
Searches video from the alarm recording area and the normal
recording area.
2 CHANNEL
Use this menu item to selects the channel for the motion sensor.
3 START PREVIEW
Search is performed based on the above selected area and
channel and the screen is
displayed.
screen
1 SEARCH FROM/CHANNEL
Displays the settings selected on the SEARCH 1> screen.
2 START/END
Used to set the start and end time of the search area and
specified channel.
3 MOTION SENSOR
Displays the motion sensor setting screen.
4 PREVIEW
When selected, displays the preview screen.
5 VIEW
The video found by the search function is played in full-screen
mode.
D Archive area search
NO DATE START CH CAPACITY
0001 01-01 01:48 1 TOTAL - 816MB
0002 05-01 09:53 1 USED - 16MB
0003 01-01 02:41 1
0004 02-01 03:10 1
0005 02-01 04:25 1
0006 04-01 02:40 1
0007 04-01 01:25 1
0008 04-01 01:25 1
MOVE:JOG SELECT:SHUTTLE
ARCHIVE AREA SEARCH SEARCH
(J)
(S)
1 2 3 4 5 6
PLAY/STOP
E Motion detection search
SEARCH FROM : ALARM
START : 01-01-06 00:40
END : 05-01-06 10:17
CHANNEL : --
START PREVIEW ->
MOVE:JOG SELECT:SHUTTLE
SEARCH FROM : ALARM / CHANNEL : 4
START :
05-01-06 10:00
END :
05-01-06 10:17
MOTION SENSOR ->
PREVIEW ->
VIEW ->
MOVE:JOG SELECT:SHUTTLE
LEVEL : OFF EXIT
1 1
2
3
4
5
2
3
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - -
- - - - - - - -
- - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
- - - - - - - - - -
