E61
PLAY/FREEZE MENU screen
Menu item
ON SCREEN
PRIORITY
BAR LEVEL
MENU RESET
VIDEO MEMORY
CLEAR
TIME ADJUST
Function/variable range
Used to set the text whitch is displayed in the video signal
output to the MONITOR terminal.
ALC EEI:
displays the ALC and EEI status during
REC mode and the iris value during
AUTO IRIS mode.
MEMORY NUM: displays the memory image number
during the PLAY mode.
BOTH: displays both sensitivity during REC
mode and memory image number dur-
ing PLAY mode.
OFF: no text is displayed for either REC mode
or PLAY mode.
Used to set which device has output priority when both
printer and MO or Zip
® drive are connected.
PRINTER: output priority is given to the printer.
MO:
output priority is given to the MO or Zip ® drive.
Used to set the level of the colour bar signal outputted
from the MONITOR terminal of this unit.
0.7V:
outputs 0.7V colour bar signals
0.58V: outputs 0.58V colour bar signals
Default value
MEMORY
NUM
DISK
0.7V
Initializes all menu switch settings other than the time, date SYNC ON G.
Resetting settings (
੬ page 64)
Clears all images stored in the main unit memory.
Clearing all images from the memory (
੬ page 40)
Calls the time and date setting screen.
Setting the time and date (
੬ page 26)
MEMO
"----" is shown in cases when ALC, EEI, and AUTO IRIS all
fail to function.
