E48
6. Menu screen settings (continued)
Setting procedure
REC normal menu screen
EXPOSURE menu (example)
Submenu screen
Menu item
Menu item Set value
REC MENU screen
1.
Press the MODE button to enter the REC mode (REC
lamp on), then press and hold the MENU for at least 2
seconds to display the REC MENU screen.
(
੬ page 10 MODE button)
(If the MENU button is not pressed long enough, the
REC mode quick menu will appear. In this case, press
the MENU button to return to the normal screen, then
press and hold the MENU button for at least 2 seconds.)
2.
Press the UP or DOWN button to select a menu item
(the menu item will be displayed in purple when se-
lected), then press the SET button to display the
submenu screen.
3.
In the submenu screen, press the UP or DOWN button
in the same manner as above to select a submenu item,
then press the SET button. The setting will be confirmed
and registered to the memory.
The set value will be displayed in purple, indicating that
it can be changed.
4.
Use the UP and DOWN buttons to change to set value,
then press the SET button to confirm (the set value will
return to white).
MEMO
• Continuous pressing of the UP or DOWN button will change
the set value in increment of 10. Use this feature when mak-
ing large changes in value.
• Pressing the MENU button without pressing the SET button
will return the setting to the previous value without making
changes.
5.
Press the MENU button twice to return to the normal
screen.
- - - - - - EXPOSURE
I R I S MODE
AE L EVE L :
:
: NORM
1
AUTO
A L
0 0
: FU L L
: ST EP
: 1 / 8 s
P : ST E
: I SO
4 0 0 : I SO
: I R I S L EVEL
I R I S DETECT
I TY
I R I S AREA
SHUT TER
SPEED
L EVE L
SEN S I T I V
A LC MAX
0
1 2 8
REC - - - MENU - - -
1 : EXPOSURE . .
2 : WH I TE BA L ANCE . .
3 : FREEZE . .
4 : PROCESS . .
5 : SYSTEM SET T I NG . .
SEE INSTRUCTION MANUAL
POWER
DC IN REMOTE
MONITOR LENS
FREEZE
PLAY
SET DOWN
AW/SEL SEND
SCSI
UP MENU
MODE
REC
ON 1 2 3 4
UP
DOWN
MODE/SET
REC lamp
MENU
