The group disable number column in TBD shows which group disable bit controls the corresponding output driver.
Group disable bits do not affect input-only pins, so those pins have a blank rather than a group number in that
column. The group disable control can control pins on either side of where the group disable boundary-scan register
cell is placed. The group disable boundary-scan register cells have a boundary-scan register order number entry, but
do not have either a corresponding pin number or signal name.
Data shifts from tdi into the most significant bit of the boundary-scan register out to tdo.
Table to be included - TBD.
16.15
VPD Registers
This section provides a description of the VPD registers. See
for theory of operation information.
Table 130. Vital Product Data (VPD) ECP ID and Next Pointer Register
•
Primary byte offset: E5:E4h
•
Secondary byte offset: E5:E4h
Bit
Name
R/W
Description
7:0
VPD ECP
ID
R
VPD Enhanced Capabilities Port ID. Read only as 03h to identify these
ECP registers as VPD registers.
15:8
VPD Next
Ptr
R
Pointer to next ECP registers. Reads as ECh to point to the next set of
ECP registers, supporting CompactPCI Hot
-
Swap.
