106 21555 Non-Transparent PCI-to-PCI Bridge User Manual
Error Handling
12.1.2 Secondary PCI Bus Error Signals
Table 28 describes the secondary PCI bus error signals .
Table 28. Secondary PCI Bus Arbitration Signals
Signal Name Type Description
s_perr_l STS
Secondary PCI interface PERR#. Signal s_perr_l is asserted when a data parity
error is detected for data received on the secondary interface. The timing of s_perr_l
corresponds to s_par driven one clock cycle earlier, and s_ad driven two clock cycles
earlier. Signal s_perr_l is asserted by the target during write transactions, and by the
initiator during read transactions.
Upon completion of a transaction, s_perr_l is driven to a deasserted state for one
clock cycle and is then sustained by an external pull-up resistor.
s_serr_l OD
Secondary PCI interface SERR#. Signal s_serr_l can be driven low by any device on
the secondary bus to indicate a system error condition. The 21555 also samples
s_serr_l as an input and conditionally forwards it to the primary bus on p_serr_l. The
21555 can conditionally assert s_serr_l for the following reasons:
• Secondary bus address parity error.
• Upstream posted write data parity error on primary bus.
• Master abort during upstream posted write transaction.
• Target abort during upstream posted write transaction.
• Upstream posted write transaction discarded.
• Upstream delayed write request discarded.
• Upstream delayed read request discarded.
• Upstream delayed transaction master timeout.
Signal s_serr_l is pulled up through an external resistor.
