140 21555 Non-Transparent PCI-to-PCI Bridge User Manual
List of Registers
16.4.2 Configuration Transaction Generation Registers
All of these registers are mapped into the 21555 configuration space and described in Section 16.4.2 . Note that the
21555 initiates a transaction only when the Configuration Data registers are accessed at these locations using I/O
reads and writes.
The Downstream Configuration Data Register and the Upstream Configuration Data Register are treated as
reserved registers for all memory accesses.
Table 45. Upper 32 Bits Downstream Memory 3 Setup Register
This register may be preloaded by serial ROM or programmed by the local processor before host
configuration.
• Primary byte offset: BF:BCh
• Secondary byte offset: BF:BCh
Bit Name R/W Description
30:0 Size R/(WS)
These bits specify upper 32 bits of the size of the address range requested
by Downstream Memory 3 BAR.
• When a bit is 1, the corresponding bit in Downstream Memory 3 BAR
functions as a readable and writable bit.
• When a bit is 0, the corresponding bit in Downstream Memory 3 BAR
functions as a read
- only bit that always returns 0 when read.
These bits must be set to a non - zero value only when bits [2:1] of
Downstream Memory 3 BAR are set to 10b (this is not enforced in
hardware).
• Reset value is 0
31 BAR_Enable R/(WS)
64 - bit Downstream Memory 3 BAR enable.
• When 0, the Downstream Memory 3 64 - bit BAR is disabled (but may
still be a 32 - bit BAR).
• When 1, the Downstream Memory 3 BAR is enabled as a 64 - bit BAR.
• Reset value is 0 (disabled)
