Maintenance Analysis Procedures
3-33
Maintenence Analysis Procedures
d. At the Switch Priority field, select Principal, Never Principal, or
Default, then click OK or Activate. The switch priority value
designates the fabric’s principal switch, which is assigned a
priority of 1 and controls the allocation and distribution of domain
IDs for all fabric elements (including itself).
Principal is the highest priority setting, Default is the next
highest, and Never Principal is the lowest priority setting. The
setting Never Principal means the fabric element is incapable of
becoming a principal switch. If all elements are set to Principal or
Default, the element with the highest priority and the lowest
WWN becomes the principal switch. At least one element in a
multiswitch fabric must be set as Principal or Default. If all
elements are set to Never Principal, all ISLs segment.
e. Set the product online. Refer to
Was the maintenance action successful?
NO
YES
↓
The fabric, ISL, and product are operational. Exit MAP.
Contact the next level of support. Exit MAP.
14
An E_Port segmented (operational product) because a response
(hello timeout) to a verification check indicates an attached switch is
not operational.
a. Perform a data collection at the operational product and contact
the next level of support. Refer to
and perform fault isolation for the
failed switch. Exit MAP.
15
Event code 072 indicates a product E_Port is connected to an
unsupported fabric element. Advise the customer of the problem and
disconnect the ISL to the unsupported fabric element. Exit MAP.
16
Event code 082 is informational only and indicates a product E_Port
is fenced (blocked). An application or hardware malfunction occurred
(as indicated by failure symptoms or primary event codes) or the port
fencing policy is too restrictive. Obtain supplementary event data as
follows:
