3-2 McDATA Sphereon 4300 Fabric Switch Installation and Service Manual
Maintenence Analysis Procedures
Quick Start
Table 3-2 lists and summarizes MAPs. Fault isolation normally begins
at MAP 0000: Start MAP .
Table 3-3 lists event codes, corresponding MAP references, and
provides a quick start guide if an event code is readily available.
Table 3-2 MAP Summary
MAP Page
MAP 0000: Start MAP 3-5
MAP 0100: Power Distribution Analysis 3-9
MAP 0200: POST Failure Analysis 3-10
MAP 0300: Loss of Browser PC Communication 3-11
MAP 0400: FRU Failure Analysis 3-14
MAP 0500: Port Failure or Link Incident Analysis 3-16
MAP 0600: Fabric or ISL Problem Analysis 3-27
Table 3-3 Event Codes versus Maintenance Action
Event
Code Explanation Action
011 Login Server database invalid. Go to MAP 0600 .
021 Name Server database invalid. Go to MAP 0600 .
031 SNMP request received from unauthorized community. Add a community name.
051 Management Server database invalid. Go to MAP 0600 .
061 Fabric Controller database invalid. Go to MAP 0600 .
062 Maximum interswitch hop count exceeded. Go to MAP 0600 .
063 Remote switch has too many ISLs. Go to MAP 0600 .
064 ESS response from indicated domain ID not received after maximum
tries. No action required.
070 E_Port is segmented. Go to MAP 0600 .
