Installation Tasks 2-17
Installation Tasks
a. Click Enable to activate the installed SNMP agent.
b. Select the appropriate Fibre Alliance management information
base (FA MIB) from the FA MIB Version drop-down list. Valid
selections are FA MIB Version 3.0 or FA MIB Version 3.1.
c. Click (check) the Enable Authentication Traps check box to
enable transmission of SNMP trap messages to recipients.
d. For each configured recipient, type a community name of 32
alphanumeric characters or less in the Name field. The name is
incorporated in SNMP trap messages to ensure against
unauthorized viewing.
e. Click (check) the box in the Write Auth column to enable write
authorization for the trap recipient (default is disabled). When
enabled, a configured user can change sysContact, sysName,
and sysLocation SNMP variables.
f. Type the IP address or DNS host name of the trap recipient
(SNMP management workstation) in the Trap Recipient field. It
is recommended the IP address be used.
g. Type a decimal port number in the UDP Port Number field to
specify the UDP port number
2. Click OK to save and activate changes.
Enable CLI Perform this procedure to toggle (enable or disable) the state of the
product’s command line interface. To change the CLI state:
1. Select CLI from the Configure menu at any view. The CLI View
displays ( Figure 2-9 ).
2. Perform one of the following:
• Click Enable to activate the CLI.
• Click Disable to deactivate the CLI.
3. Click (check) the Use SSH check box to enable secure shell (SSH)
protocol. The protocol controls CLI access to the product and
provides software-enforced encryption.
4. Click OK to save and activate changes.
