Repair Information 4-13
Repair Information
• Operational State - Port state (Online, Offline, Not Installed,
Inactive, Invalid Attachment, Link Reset, No Light, Not Operational,
Port Failure, Segmented E_Port, or Testing).
• Type - Configured port type. Settings are:
— Generic mixed port (GX_Port). This setting also
configures a port as a generic loop port (GL_Port).
— Fabric mixed port (FX_Port). This setting also
configures a port as a fabric loop port (FL_Port).
— Generic port (G_Port).
— Fabric port (F_Port).
— Expansion port (E_Port).
• Health Status - Condition of the installed optical transceiver
(Normal, Warning, Alarm, or No Info).
• Transceiver - Installed transceiver type (SFP, XFP, or Unknown).
Inspect Port Properties
At the Port List View, click a physical port number listed in the Port
column. Physical properties for the selected port appear in the lower
panel of the view:
• Port Number - Product port number.
• Port Name - User-defined name or description for the port.
• Port Type - User-defined port type (GX_Port, FX_Port, G_Port,
F_Port, or E_Port).
• Operating Speed - Port operating speed (Not Established, 1 Gbps,
or 2 Gbps).
• Fibre Channel Address - Port FC address identifier. Port FC
address if the port was swapped.
• Port WWN - Fibre Channel world wide name (WWN) of the port.
• Attached Port WWN - Fibre Channel WWN of the device
attached to the port.
• Block Configuration - User-configured state for the port (Blocked
or Unblocked).
• Beaconing - User-specified for the port (On or Off).
