McDATA Sphereon 4300 Fabric Switch Installation and Service Manual
Maintenence Analysis Procedures
Change the port speed to be compatible with the backplane or optical
transceiver speed.
a. Select Ports and Basic Info from the Configure menu at any
view. The Basic Information View displays.
b. If necessary, use the vertical scroll bar to display the information
row for the inactive port.
c. Select (click) the Speed field and configure the port.
d. Click OK or Activate.
Was the maintenance action successful?
NO
YES
↓
The product port is operational. Exit MAP.
Contact the next level of support. Exit MAP.
16
As indicated by event codes 506, 512, 514, 515, or 516, a port failed
and the optical transceiver must be removed and replaced. Refer to
RRP 1: SFP Optical Transceiver
.
•
The procedure is concurrent and performed while the product is
operational.
•
Replace the transceiver with a transceiver of the same type
(shortwave or longwave) and speed.
•
Perform an external loopback test. Refer to
NOTE: Event code 514 may generate a call-home event that incorrectly
indicates a CTP card failure. Although the optical socket on the CTP card
may have failed, replace the transceiver and verify operation. If a failure is still
indicated, replace the switch. When event code 514 is indicated, ensure a
replacement transceiver and switch are available.
Was the maintenance action successful?
NO
YES
↓
The product port is operational. Exit MAP.
Contact the next level of support. Exit MAP.
