A-34
McDATA Sphereon 4300 Fabric Switch Installation and Service Manual
Event Code Tables
Event Code: 514
Message:
Optical transceiver failure.
Severity:
Major.
Explanation:
An optical transceiver failed. The amber LED corresponding to the port illuminates to indicate the failure. Ports
with LEDs extinguished remain operational.
Action:
Replace the failed transceiver.
Event Data:
Byte 0 = port number.
Byte 1 = engineering reason code.
Byte 2 = optic type.
Bytes 4 - 7 = elapsed millisecond tick count.
Bytes 8 - 11 = optic serial number.
Distribution:
Product
Management Server
Host
EFCM Basic
Event Log
System
Error LED
Event Log
Call-Home
Sense Info
Link Incident
Log
✔
✔
✔
Event Code: 515
Message:
Optical digital diagnostics warning threshold exceeded.
Severity:
Minor.
Explanation:
An optical transceiver digital diagnostics warning threshold was exceeded. Additional event code 515 events are
recorded if the problem persists.
Action:
Replace the transceiver.
Event Data:
Byte 0 = port number.
Byte 2 = optic type.
Bytes 4 - 7 = elapsed millisecond tick count.
Bytes 8 - 31 = First, second, and third type (and threshold value) of warning threshold exceeded as follows:
01 = TX temperature, 02 = TX supply voltage, 03 = TX bias current, 04 = TX power, 05 = RX power.
Distribution:
Product
Management Server
Host
EFCM Basic
Event Log
System
Error LED
Event Log
Call-Home
Sense Info
Link Incident
Log
✔
✔
✔
