3-4 MC68VZ328 User’s Manual
Programmer’s Memory Map
0xFFFFF42A PFPUEN 8 Port F pull-up/pull-down enable
register 0xFF 10-27
0xFFFFF42B PFSEL 8 Port F select register 0x87 10-27
0xFFFFF430 PGDIR 8 Port G direction register 0x00 10-28
0xFFFFF431 PGDATA 8 Port G data register 0x3F 10-28
0xFFFFF432 PGPUEN 8 Port G pull-up enable register 0x3D 10-30
0xFFFFF433 PGSEL 8 Port G select register 0x08 10-31
0xFFFFF438 PJDIR 8 Port J direction register 0x00 10-31
0xFFFFF439 PJDATA 8 Port J data register 0xFF 10-32
0xFFFFF43A PJPUEN 8 Port J pull-up enable register 0xFF 10-33
0xFFFFF43B PJSEL 8 Port J select register 0xEF 10-33
0xFFFFF440 PKDIR 8 Port K direction register 0x00 10-34
0xFFFFF441 PKDATA 8 Port K data register 0x0F 10-35
0xFFFFF442 PKPUEN 8 Port K pull-up/pull-down enable
register 0xFF 10-36
0xFFFFF443 PKSEL 8 Port K select register 0xFF 10-36
0xFFFFF448 PMDIR 8 Port M direction register 0x00 10-37
0xFFFFF449 PMDATA 8 Port M data register 0x20 10-38
0xFFFFF44A PMPUEN 8 Port M pull-up/pull-down enable regis-
ter 0x3F 10-39
0xFFFFF44B PMSEL 8 Port M select register 0x3F 10-40
0xFFFFF500 PWMC1 16 PWM unit 1 control register 0x0020 15-4
0xFFFFF502 PWMS1 16 PWM unit 1 sample register 0xxxxx 15-6
0xFFFFF504 PWMP1 8 PWM unit 1 period register 0xFE 15-7
0xFFFFF505 PWMCNT1 8 PWM unit 1 counter register 0x00 15-7
0xFFFFF506 RES 16 Reserved — —
0xFFFFF510 PWMC2 16 PWM unit 2 control register 0x0000 15-8
0xFFFFF512 PWMP2 16 PWM unit 2 period register 0x0000 15-9
0xFFFFF514 PWMW2 16 PWM unit 2 width register 0x0000 15-10
0xFFFFF516 PWMCNT2 16 PWM unit 2 counter register 0x0000 15-10
Table 3-1. Programmer’s Memory Map (Sorted by Address) (Continued)
Address Name Width Description Reset Value
Page
Number
