DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 99
DCA-220SSK — ENGINE & RADIATOR ASSY.
ENGINE & RADIATOR ASSY. S/N1337563 TO 3690734
NO PART NO PART NAME QTY. REMARKS
31 0602022294 HOSE JOINT 1
32 0265800260 DRAIN HOSE 1
33 0605515074 HOSE BAND 2
34 0132008000 PLUG 1
35 0802081003 RESERVE TANK 1
36 0602010900 CAP, RESERVE TANK 1
37 C1317100103 BRACKET, RESERVE TANK 1
38 0193601300 HOSE 1
39 0199601300 HOSE 1
40 0193600550 HOSE 1
41 0605515013 HOSE BAND 4
42 0194800750 HOSE 1
43 C1327100103 BREATHER PIPE 1
44 0017108020 HEX. HEAD BOLT 2
45 0603320111 U BOLT 1
46 0207008000 HEX. NUT 2
47 0268500650 HOSE 1
48 0605515073 HOSE BAND 2
49 C1358300804 CLAMPER ROD 1
50 0017110020 HEX. HEAD BOLT 4
51 C1358300104 CLAMPER ROD 1
52 0017110020 HEX. HEAD BOLT 1
53 0010016030 HEX. HEAD BOLT 1
54 0040016000 LOCK WASHER 1
55 0041216000 PLAIN WASHER 1
