DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 87
1 C1224000503 CONTROL PANEL 1
2 C1224000603 CONTROL PANEL 1
3 0605011211 PIN 2
4 0601807622 FREQ. METER ............................................. 1 ............ RSC80F 45~65Hz 200V
5 0601806980 AC AMMETER .............................................. 1 ............ RSS80 0~400A
6 0601801040 CHG.OVR. SW.-AMMETER .......................... 1 ............ SL2AS
7 0601806887 AC VOLTMETER ........................................... 1 ............ RSR80 0~600V
8 0601801041 CHG.OVR.SW-VOLTMETER ......................... 1 ............ SL2VS
9 0601810072 PILOT LAMP ................................................. 1 ............ KO132DC 220V
0601810261 BULB 1
10 0601840073 RHEOSTAT (VOLTAGE REGULATOR) .......... 1 ............ RA20A2SE102BJ
11 060184012 KNOB 1
12 0601810161 PANEL LIGHT 1
0601810214 BULB 1
13 0207004000 HEX. NUT 2
14 0601830710 SWITCH, PANEL LIGHT 1
15 C9221100004 HEX. HEAD BOLT 2
0040008000 LOCK WASHER 2
0041208000 PLAIN WASHER 2
0080200007 SNAP RING 2
16 0017108040 HEX. HEAD BOLT 4
17 ECU9988N* ENGINE CONTROLLER ............................... 1 ............ REPLACES 0602202545
18 0601831340 SWITCH,82608DPDT .................................... 1 ............ S/N3696501 TO3698120
18 0601830765 SWITCH,S3037; ............................................ 1 ............ S/N3698121~
19 DYNT11100 SPEED SENSOR ......................................... 1 ............ S/N3696501~;
REPLACES 0602120497
DCA-220SSK — CONTROL PANEL ASSY.
CONTROL PANEL ASSY. S/N1337563~
NO. PART NO. PART NAME QTY. REMARKS
*NOTE:
WHEN ORDERING PART NUMBER 17,
PLEASE INDICATE SERIAL NUMBER.
