DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 109
DCA-220SSK — ENGINE OPERATING AND OUTPUT TERMINAL ASSY.
ENGINE OPERATING AND OUTPUT TERMINAL ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
69 0025004016 MACHINE SCREW 2
0042304000 LOCK WASHER 2
0042404000 PLAIN WASHER 2
70 0601802010 CIRCUIT BREAKER ................................. 1 .........KM-2 220V 15A
71 0845032304 BRACKET, CIRCUIT BREAKER 1
71-1 0223300060 RUBBER CUSHION 1
72 0019106020 HEX. HEAD BOLT 4
0042306000 LOCK WASHER 4
0042406000 PLAIN WASHER 4
73 0601811262 RECEPTACLE REMOTE CONTROL ........ 1 ......... NWPC-254-RF
74 0601811409 CAP, RECEPTACLE ................................. 1 ......... NWPC-25-RCa
75 0845044604 BRACKET 1
76 0027103010 MACHINE SCREW ................................... 3 .........REPLACES 0021103010
77 0025013010 MACHINE SCREW 3
0042303000 LOCK WASHER 3
0042403000 PLAIN WASHER 3
78 0021003010 MACHINE SCREW 1
0040003000 LOCK WASHER 1
0021103010 PLAIN WASHER 1
79 8185182003 COVER, OUTPUT TERMINAL 1
80 0019112045 HEX. HEAD BOLT 2
81 0042412000 PLAIN WASHER 4
82 0805009804 RUBBER WASHER 2
83 0205012000 HEX. NUT 2
84 0845043704 LOCK 2
85 0040506000 TOOTHED WASHER 1
86 011206020 HEX. HEAD BOLT .................................... 1 .........REPLACES 0017106020
