DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 129
DCA-220SSK — MUFFLER ASSY.
MUFFLER ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
1 8182311002 MUFFLER 1
2 0019110030 HEX. HEAD BOLT 4
3 0042310000 LOCK WASHER 4
4 0042410000 PLAIN WASHER 4
5 8182350003 EXHAUST PIPE 1
6 6150115750 GASKET .................................. 1 ........... REPLACES 0602320059
7 7502356004 GASKET 2
8 0010312060 HEX. HEAD BOLT 8
9 0030312000 HEX. NUT 8
10 0040012000 LOCK WASHER 8
11 031112230 PLAIN WASHER ...................... 16 ......... REPLACES 0041612000
MUFFLER ASSY. S/N1337563~
NO PART NO PART NAME QTY. REMARKS
1 C1331100702 MUFFLER 1
2 0019210025 HEX. HEAD BOLT 4
3 C1334000403 EXHAUST PIPE 1
4 6150115751 GASKET .................................. 1 ........... REPLACES 0602320142
5 7502356004 GASKET 1
6 0010312050 HEX. HEAD BOLT 4
0030312000 HEX. NUT 4
0040012000 LOCK WASHER 4
0041212000 PLAIN WASHER 8
7 0010312055 HEX. HEAD BOLT 4
0030312000 HEX. NUT 4
0040012000 LOCK WASHER 4
0041212000 PLAIN WASHER 8
8 C1331300104 COVER 2
9 C1334200104 SHEET 2
10 0017108020 HEX. HEAD BOLT 4
11 C1334300104 BRACKET 1
12 0017108020 HEX. HEAD BOLT 4
13 0603320129 U BOLT 2
14 0207010000 HEX. NUT
