DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 79
DCA-220SSK — CONTROL BOX AND PANEL ASSY.
CONTROL PANEL ASSY. UP TO S/N1337562
NO. PART NO. PART NAME QTY. REMARKS
1 8181812502 CONTROL BOX 1
2 0601801167 TRANSFORMER, AMMETER ............................ 2 ...... CT5MR 400/5A
3 0027106010 MACHINE SCREW 4
4 0601805950 CIRCUIT BREAKER ........................................... 1 ...... TO-600CA 600A
5 0601820625 AUTOMATIC VOLTAGE REGULATOR 1
6 0027105012 MACHINE SCREW 4
7 0601820193 CONDESER ........................................................ 1 ...... 40FAL 155U#L2
8 0027103010 MACHINE SCREW 2
9 0601820851 OVER CURRENT RELAY .................................... 1 ...... THK20
10 0027104016 MACHINE SCREW 2
11 0601823757 RELAY ................................................................ 2 ...... MY2 DC24V
12 0601823143 SOCKET, RELAY ................................................ 2 ...... PYF 08A
PYCA1 HOLDER ............................................................. 2 ...... REPLACES 0601824400
13 0027104016 MACHINE SCREW 4
14 0601823240 RECTIFIER ......................................................... 1 ...... DE4503
15 0027105016 MACHINE SCREW 1
16 0801850004 RESISTOR UNIT 1
17 0021005020 MACHINE SCREW 1
0040050000 LOCK WASHER 1
0041205000 PLAIN WASHER 1
0030006000 HEX. NUT 1
18 0601830715 SELECTOR SWITCH, VOLTAGE ........................ 1 ...... S332T
19 8181861103 SET BOARD, CHANGE TERMINAL 1
20 8181852104 CHANGE TERMINAL 10
21 0017106025 HEX. HEAD BOLT 20
22 8181853104 CHANGE PLATE 6
23 8131852504 HEX. HEAD BOLT 10
24 0801831804 HEX. HEAD BOLT 16
25 0040010000 LOCK WASHER 26
26 0041410000 PLAIN WASHER 26
27 0017108030 HEX. HEAD BOLT 4
28 8181822603 CONTROL PANEL 1
29 8181822503 CONTROL PANEL 1
29-1 0225100095 RUBBER SEAL 4
30 0605011211 PIN 4
Control Box and Panel up to S/N1337562 Cont. Panel S/N1337563~ Cont. Box S/N1337563~
