DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 73
NO PART NO PART NAME QTY. REMARKS
19 0845044904 GROMMET 1
20 012212045 HEX. HEAD BOLT ...................... 8 ......... REPLACES 0010112045
21 0040012000 LOCK WASHER 8
22 031112230 PLAIN WASHER ........................ 8 ......... REPLACES 0041612000
23 8171310004 COVER, BEARING 1
24 8171312004 GASKET, BEARING 1
25 8171331003 COVER, END BRACKET 1
26 0010106016 HEX. HEAD BOLT 12
27 0040006000 LOCK WASHER 12
28 952404470 PLAIN WASHER ........................ 12 ........ REPLACES 0041606000
29 8171333003 COVER, END BRACKET 1
30 0010106030 HEX. HEAD BOLT 2
31 0040006000 LOCK WASHER 2
32 952404470 PLAIN WASHER ........................ 2 ......... REPLACES 0041606000
33 0012112035 HEX. HEAD BOLT 12
34 0042512000 LOCK WASHER 12
35 8171332003 COVER, FAN 1
36 0605000012 RUBBER SUSPENSION 2
37 0030020000 HEX. NUT 4
38 030220510 LOCK WASHER ......................... 4 ......... REPLACES 0040020000
DCA-220SSK — GENERATOR ASSY.
GENERATOR ASSY. UP TO S/N1337562
