DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 77
DCA-220SSK — GENERATOR ASSY.
GENERATOR ASSY. S/N1337563~
10 0012110065 HEX. HEAD BOLT 4
0042610000 LOCK WASHER 4
0041210000 PLAIN WASHER 4
11 0017112045 HEX. HEAD BOLT 6
12 C1154400004 COVER, BEARING 1
13 C1154300004 GASKET, BEARING 1
14 0010106065 HEX. HEAD BOLT 4
0040006000 LOCK WASHER 4
0041206000 PLAIN WASHER 4
15 C1154400103 SUCTION COVER 1
16 0017106016 HEX. HEAD BOLT 8
17 0012112035 HEX. HEAD BOLT 12
18 0042512000 LOCK WASHER 12
19 C1132300103 COVER, FAN ........................................ 1 .......... S/N3690735 TO 3692206
19 C1132300114 COVER, FAN ........................................ 1 .......... S/N3692207~
20 0010106030 HEX. HEAD BOLT 1
0041206000 PLAIN WASHER 1
0600815000 NUT ....................................................... 1 .......... S/N3692207~
21 0605000012 RUBBER SUSPENSION 2
22 0030020000 HEX. NUT 4
0040020000 LOCK WASHER 4
NO PART NO PART NAME QTY. REMARKS
