DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 71
GENERATOR ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
1 8181000002 ROTOR ASSY. 1
1-1 FIELD ASSY. 1
1-2 8171070002 FAN 1
1-3 0012112040 HEX. HEAD BOLT 8
1-4 0042512000 LOCK WASHER 8
1-5 8171611003 COUPLING DISK 9
1-6 8171015003 BALANCING PLATE 1
1-7 0012116040 HEX. HEAD BOLT 8
1-8 0042616000 LOCK WASHER 8
1-9 8171026003 SET PLATE, RECTIFIER 1
1-10 0601821349 RECTIFIER ................................................ 3 ........ PT 3610
1-11 0601822615 SURGE ABSORBER ................................. 1 ........ ERZ-M20JK621B
1-12 8171020004 INSULATOR WASHER 1
1-13 8171020504 INSULATOR WASHER 1
1-14 0010110020 HEX. HEAD BOLT 6
1-15 0040010000 LOCK WASHER 6
1-16 0601000209 BALANCING WEIGHT KIT 1
1-17 0070806312 BEARING ................................................... 1 ........ 6312 DU
1-18 0080000060 SNAP RING 1
2 8171614003 COUPLING RING 1
3 0012112035 HEX. HEAD BOLT 8
4 0042512000 LOCK WASHER 8
5 8181340303 STATOR ASSY. 1
5-1 0226100430 RUBBER SEAL 1
6 8171323004 CLAMPER 1
6-1 0223300120 RUBBER SEAL 1
7 8171323103 CLAMPER 1
7-1 0221200300 RUBBER SEAL 1
8 0010110035 HEX. HEAD BOLT 2
9 031110160 PLAIN WASHER ........................................ 2 ........ REPLACES 0041610000
10 8171324003 COVER 1
10-1 0226000270 RUBBER SEAL 2
10-2 0225000480 RUBBER SEAL 1
11 0010106016 HEX. HEAD BOLT 6
12 0040006000 LOCK WASHER 6
13 031110160 PLAIN WASHER ........................................ 6 ........ REPLACES 0041606000
14 8171315002 END BRACKET 1
15 8171350003 FIELD ASSY., EXCITER 1
16 0012110060 HEX. HEAD BOLT 6
17 0042610000 LOCK WASHER 6
18 031110160 PLAIN WASHER ........................................ 6 ........ REPLACES 0041610000
DCA-220SSK — GENERATOR ASSY.
